Total 9 Records |
|||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size | Images | Module Name | Brand | Touch Panel | Aspect Ratio | Contrast Ratio | Tech Type | Resolution | Active Area(mm) | Luminance (nits) |
NTSC | Viewing Angle | Interface | ||
7"
 |
|
EJ070NA-01K | CHIMEI-INNOLUX | Optional | 16:9 | 500:1 | TFT | 800*3(RGB)*480 | 154.08 x 85.92 | 400 | 50% | 50/70/70/70 | 50pin FPC Parallel RGB(1 ch,6/8-bit) | ||
|
7"
|
|
AT070TN94 | CHIMEI-INNOLUX | Optional | 16:9 | 500 | TFT | 800*3(RGB)*480 | 154.08 x 85.92 | 400 | 50% | 50/70/70/70 | 50pin FPC, Parallel 24bit RGB | ||
|
7"
|
|
AT070TN92 | CHIMEI-INNOLUX | Optional | 16:9 | 500 | TFT | 800*3(RGB)*480 | 154.08 x 85.92 | 250 | 50% | 50/70/70/70 | 50pin FPC, Parallel 24bit RGB | ||
|
7"
|
|
LW700AT9309 | CHIMEI-INNOLUX | Optional | 15:9 | 400:1 | TFT | 800*3(RGB)*600 | 152.40 x 91.44 | 350 | 45% | 60/70/70/70 | 40pin TTL (1 ch, 6-bit) | ||
|
7"
|
|
ZJ070NA-01P | CHIMEI-INNOLUX | Optional | 17:10 | 700:1 | TFT | 1024*3(RGB)*600 | 153.6 x 90.0 | 500 | 70% | 70/75/75/75 | 40pin FPC, LVDS | ||
|
7"
|
|
HJ070NA-13A | CHIMEI-INNOLUX | Optional | 17:10 | 700:1 | TFT | 1024*3(RGB)*600 | 153.6 x 90.0 | 250 | 70% | 70/75/75/75 | 40pin FPC, LVDS | ||
|
7"
|
|
AT070TN07 V.D | CHIMEI-INNOLUX | Optional | 16:9 | 300 | TFT | 480*3(RGB)*234 | 154.08 x 86.58 | 200 | 50% | 40/60/60/60 | Analog(26 Pin FPC) | ||
|
7"
|
|
AT070TN84 V.1 | CHIMEI-INNOLUX | Optional | 15:9 | 500 | TFT | 800*3(RGB)*480 | 152.4 X91.44 | 450 | 50% | 50/70/70/70 | 60pin FPC(2*30pin), Parallel 18bit RGB | ||
|
7"
|
|
AT070TN83 V.1 | CHIMEI-INNOLUX | Optional | 15:9 | 500 | TFT | 800*3(RGB)*480 | 152.4 x 91.44 | 300 | 50% | 50/70/70/70 | 40pin, 18bitRGB connector | ||
Total 9 Records |
|||||||||||||||
