EJ101IA-01G
MOQ: ≥ 10pcs
Lead Time: 3 working days FCA Hongkong after receiving PO
Payment: T/T, Paypal, West Union
Warranty: 1year
Lead Time: 3 working days FCA Hongkong after receiving PO
Payment: T/T, Paypal, West Union
Warranty: 1year
Chi mei InnoLux TFT LCD panel display EJ101IA-01G module parameter:
|
Product Name: |
EJ101IA-01G |
|
Touch Panel: |
Optional |
|
Screen Size: |
10.1" |
|
Aspect Ratio: |
16:10 |
|
Display Mode: |
Transmissive |
|
Resolution: |
1028X3(RGB)X800 |
|
PPI ( Pixel per inch ): |
149 |
|
Module/Panel Size(mm): |
229.46 x 149.1 x 2.5 |
|
Active Area(mm): |
216.96 x 135.60 |
|
Dot Pitch(mm): |
- |
|
Surface Treatment: |
Hard Coating |
|
Viewing Angle (Tpy.)θT/θB/θL/θR: |
85/85/85/85 |
|
Viewing direction: |
Symmetry |
|
NTSC: |
50% |
|
Luminance(nits): |
350 |
|
Contrast Ratio: |
800:1 |
|
Response Time(ms): |
10/15 (Typ.)(Tr/Td) |
|
Consumption (W)- Total: |
2.86 |
|
Color Depth: |
16.7M |
|
Weight (g): |
183.0 |
|
Interface: |
40pin Connector LVDS (1 ch, 8-bit) |
|
Operation Temperature( ℃): |
-15~50 |
|
Storage Temperature (℃): |
-20~60 |
|
Lamp Type: |
White LED backlight Display |
